TruEcho CHIRP Black Box Fish Finder Module for NavNet TZtouch2

Find A Dealer

Find More Fish with TruEcho CHIRP™ Fish Finder

Designed to operate over a broadband range of frequencies utilising a broadband CHIRP transducer, the TruEcho CHIRP™ network sounder DFF1-UHD delivers significant advancements in signal clarity and target definition. The clear presentation of the sounder marks individual game fish and bait fish, even when tightly schooled together.

Clear presentation separates bottom structure from bottom fish, and bait fish from game fish

TruEcho CHIRPTM sweeps across 90 frequencies

The DFF1-UHD uses a precise sweep pattern across 90 frequencies (50 kHz +/- 20 kHz, 200 kHz +/- 25 kHz) within a long-duration transmission. The equivalent sound energy transmitted into the water is 10 to 1,000 times greater than a conventional Fish Finder, resulting in more energy on target. The results are up to 5x greater resolution and depth capability than comparably powered, standard Fish Finders due to the advanced signal processing of the return echo.

Network fish finder works with NavNet 3D/TZtouch/TZtouch2

  • Frequency: Dual Frequency 50 ± 20 & 200 ± 25 kHz
  • Transducer: 1 kW
  • ACCU-FISH: Available
  • Bottom Discrimination: Available
  • Waterproofing: IP55
  • Power Supply: 12-24 VDC, 2.8-1.4 A
  • Dimensions: 316 (H) x 380 (W) x 120 (D) mm
  • Weight: 3.1 kg
